Metal processing machinery » Machining centers (universal) » Centers (universal) over 1000mm (x-travel) »
CMS ARES 36 18 NEWPX5 5 axis universal machining center
inv. num. : 4730
Type: ARES 36/18-NEWPX5
Producer: CMS
Produced: 2008
parameters:
Work table length: 3640 mm
Working table width: 1360 mm
Tool magazine: 8 pieces
mechanical feed length axis X: 3600 mm
Mechanical feed length axis Y: 1800 mm
Mechanical feed length axis Z: 1200 mm
Maximum feed rate axis X: 80 m/min
Maximum feed rate axis Y: 80 m/min
Maximum feed rate Z axis: 70 m/min
Total power consumption: 12-15 kVA
Cone: HSK 63F
Number of axes: 5 pieces
Electrical spindle speed: 12000 1/min
The thickness of the working table:: 30 mm
Equipment:
Swivel head (2 axes)
Universal head
Fzzqkyh
ICZ
Switchgear
Air conditioning
Aluminium table with T-slots
Remote control FANUC button
Pneumatic brakes
Dust protection
The advertisement was translated automatically and some translation errors may have occurred.
Machine Data | |||||||||||||||
| Machine ID | WM226574 | ||||||||||||||
| Machine type | 5-axis universal machining center | ||||||||||||||
| Manufacturer | CMS | ||||||||||||||
| Model | ARES 36/18-NEWPX5 | ||||||||||||||
| Year of manufacture | 2008 | ||||||||||||||
| Condition | good (used) | Price and Location | |||||||||||||
| Location | Brno , Czech Republic | ||||||||||||||
