x travel 800 mm
y travel 650 mm
z travel 550 mm
—–
WORKING RANGE -CUBIC-
– number of processing axes (excl parallel axes) 3
– X-axis travel 800 mm
– Y-axis travel 650 mm
– Z-axis travel 550 mm
TABLE
– table surface (left-right) 1100 mm
– table surface (front-back) 650 mm
– workpiece load (max) 450 kg
MILLING SPINDLE / HEAD
– spindle type: horizontal
– tool fixture: ISO SK 40
– drive power 16 kW
AXIS DRIVES
– feed velocity (min) 15000 mm/min
TOOL MAGAZINE
– number of positions 25
ELECTRICAL SPECIFICATIONS
– total power consumption 29 kW
Cwl90zhk
DIMENSIONS / WEIGHTS
– space requirements -left/right- 3200 mm
– space requirements -front/back- 3200 mm
– total height 2500 mm
– total weight approx. 5500 kg
ATTACHMENTS
– European CE standards: yes
