x travel 1250 mm
y travel 880 mm
z travel 800 mm
—–
WORKING RANGE -CUBIC-
– X-axis travel 1250 mm
– Y-axis travel 880 mm
– Z-axis travel 800 mm
TABLE
– table surface (left-right) 1500 mm
– table surface (front-back) 1050 mm
– workpiece load (max) 2500 kg
MILLING SPINDLE / HEAD
– spindle revolutions (min) 20 /min
– spindle revolutions (max) 18000 /min
– tool fixture: ISO SK 40
– drive power 15 kW
AXIS DRIVES
– feed velocity (min) 20 mm/min
– feed velocity (max) 10000 mm/min
Bgwdoz7ci2
– rapid traverse 40000 mm/min
TOOL MAGAZINE
– number of positions 32
DIMENSIONS / WEIGHTS
– space requirements -left/right- 7200 mm
– space requirements -front/back- 6100 mm
– total height 3100 mm
– total weight approx. 12500 kg
ATTACHMENTS
– chip conveyor: yes
