TOS Hostivař BHU 40 A 1500 Cylindrical grinding machine
General repair: 2016
Swing diameter 400mm
Distance between centers 1500mm
Grinding wheel: diameter x width x hole 600x100x305
Taper in the driving spindle Morse 5
Cone in Morse tailstock 5
Maximum grinding wheel width 150mm
Swing in open arm 110mm
Rotation of grinding headstock + -45 °
Table rotation on both sides 5 °
Weight of machine with standard accessories 5950Kg
Grinding spindle speed 1240 rpm
Drive spindle speed 16 degrees
1 row – 12, 20, 32, 50, 80, 125, 200, 315 rpm
2 rows – 16, 25, 40, 63, 100, 160, 250, 400 rpm
Smallest longitudinal movement of 1mm
Largest longitudinal movement of table 1790mm
Table speed infinitely controllable 0.05-5 m / min
Table speed infinitely controllable on headstock when grooving 0.1-5 mm / min
Total motor power 22 kVA
Grinding headstock motor 15 kW
Maximum workpiece weight 300 kg
Bhqzeg8krj
Machine accessories:
• Grinding wheel
• Dresser
• Set of hearts
Machine Data | |||||||||||||||
Machine ID | WM229529 | ||||||||||||||
Machine type | Cylindrical grinding machine | ||||||||||||||
Manufacturer | TOS Hostivař | ||||||||||||||
Model | BHU 40 A 1500 | ||||||||||||||
Condition | excellent (used) | Price and Location | |||||||||||||
Location | Brno , Czech Republic | ||||||||||||||
